Model 3D UV Minder® UV Meter
back
Model 3D UV Minder® Intensity Meter accurately measures the UVA and UVB spectra for SPF testing, cosmetics research, dermatology, environmental research, agriculture, and forestry.
Description
Model 3D UV Minder® Intensity Meter accurately measures the UVA and UVB spectra with its on-board UVA and UVB sensors. The meter shows the intensity of UVB (also called SUV – Sunburning UV) in Minimal Erythemal Doses per Hour (MED/Hr), the accepted clinical measure for sunburn potential. The UVA sensor measures UV intensity in the 320-400nm range, displaying UVA irradiance in mW/cm2. We also offer a special Model 3D-XP Xeroderma Erythemal UV Intensity Meter for measuring very low UV intensity, down to 3 decimal places, for XP patients. Please specify wavelength range required when ordering. The 3D meter is durable, simple to use, and extremely accurate.
Application
- SPF testing
- Cosmetics Research
- Dermatology
- Xeroderma Pigmentosum
- Environmental Monitoring
- Environmental Research
- Agriculture and Forestry
Input Ranges
Resolution
Operating
Environment
Power Source
Power Consumption
Battery Life
UVB (SUV) 0.19.99 MED/Hr
UVA 0.19.99 mW/cm2
0.01 MED/Hr or mW/cm2
32 to 120°F (0 to +50°C)
9 volt Alkaline Batteries
<300μA
>40 Hours Continuous Use
External Power
9-12V AC or DC Adapter
LCD Size
3.5 Digit
Size (WxDxH)
3.75”x5.5”x3.4” (9.5x14x8.6 cm)
Weight
8 oz. (227 grams)
