Skin Pigmentation Analyzer SPA 99

sales@dproscientific.com

+6 (03) 7960 4710

back

DOWNLOAD

Determine your Customers' Skin Colour

Recommended instrument for advising on sun care, skin whiteners, and IPL/laser treatment consultation by the measurement of pigmentation (melanin content) and erythema level (redness) quickly in one measurement (1 second). The display shows the result for both parameters on a scale from 0-99.

Advantages of the SPA 99
The measurement of those main colour giving parameters for the skin is not only important for product promotion of sun screen, whiteners or anti-allergic products but also in dermatology to look at irritation and to support IPL/laser treatment consultation.
Battery-operated unit can easily be moved around and transported. Ask for special transportation suitcases.

It can also be operated with the software Dermacheck 3000 especially suitable for aesthetic practice/institute to do single measurements and laser/IPL treatment consulting. The software is modular and license based (your device has to be equipped with an active USB-port).
Technical Data
Device:
Dimensions: 15 x 14 x 4.5 cm
Weight: approx. 0.5 kg
Port: USB 2.0 Type B
built-in sebum measurement and two probe connectors
Power supply: 9 V battery

Melanin/Pigmentation & Erythema probe:
Measurement: absorption/reflection
Nominal wavelengths: 3 colours measuring system green: λ peak = 568 nm, red: λ peak = 660 nm, infrared: λ peak = 880 nm
Time: 1 second
Scale: 0-99 for both measurements
Dimensions: 13 x Ø 2.4 cm
Weight: 85 g
Cable length: 1.3 m
Port: USB 2.0, type B connector (not all devices)

Technical changes may be made without prior notice.
