Multi Skin Test Center MC 750

• What can the device do?

  The device allows you to create your own measurement system by selecting probes of your choice.



  The basic system consist of:



  • measurement of skin hydration
  • oil (sebum) content assessment on skin and hair

















  • Add other probes optionally to the system:
  • Measure skin’s elasticity (biological skin age) by suction (ability of the skin to resist/firmness versus its ability to return to the original position, displayed in %). Since the elasticity measurement needs a vacuum box inside the device to create the pressure, it must be ordered with the basic model and cannot be added later.
  • Assess skin pigmentation and redness (erythema), TEWL index (the quality of the skin barrier), pH-measurement and skin temperature for the assessment of micro circulation.















  • Visioscope® PC 35 USB skin camera with parallel and cross polarized light makes the system complete.







  • Special foils Sebufix® F 16 and Cornoefix® F 20 in convenient dispensers usable with the camera to perform quantitative analysis of sebum production and desquamation (chart interprets the images visible on the monitor). The Sebufix® mounted on the Visioscope® Camera shows the sebum production in real time on the monitor.







  • The sophisticated and attractive software SCS – Skin Competence System supports the device. It offers a guided facial analysis tour, free measurements with probes and camera on face and body and much more.















• Advantages of the Multi Skin Test Center MC 750

  • Start with only a few probes and enlarge your measurement centre with time.
  • Ideal tool for all who want to do a comprehensive, impressive skin analysis. Together with the attractive, modern software SCS – Skin Competence System it will take your cosmetic consulting to a new level.
  • You have the choice between 7 important probes and 2 cameras, Visioscope® and Visiopor®, with different illumination modes. More than 15 different measurement parameters are to your disposal.
  • Increase the sales of your products and treatments by giving expert recommendation founded on various, scientific-based measurements. Ideally suited to maximize your success by competent skin analysis at the POS and in esthetic institutes.



• Technical Data

  Device: Dimensions: 33 x 28 x 11 cm, Weight: model A: approx. 2.4 kg, model B: approx. 2.9 kg, External power supply: 100-240 VAC/12VDC, Port: USB 2.0, type B connector



  Moisture: Measurement: capacitance, Time: 1 second, Scale 0-99, Frequency: 0.9-1.2 MHz, Dimension: 11 cm, Weight: 41 g, Cable length: 1.3 m



  Sebum: Measurement: photometrical, Time: 10 seconds, Scale 0-99, Dimensions: 8.5 x 11.3 x 2.3 cm, Weight: 65 g, Number of measurement: approx. 400-450 (if the trigger is only pulled down slowly for the next free measuring section). When tape is consumed, the whole cartridge has to be renewed



  Optional probes/cameras:



  Elasticity: Measurement: suction with 400 mbar pressure, Time: 6 seconds (3 seconds suction/3 seconds relaxation), Scale 0-99, Probe opening: 2 mm Ø, Dimensions: 13 cm x Ø 2.4 cm, Weight: 95 g, Cable length: 1.3 m



  Melanin/Pigmentation: Measurement: absorption/reflection, nominal wavelengths: 3 colour measuring system green: λ peak = 568 nm, red: λ peak = 660 nm, infrared: λ peak = 880 nm, time: 1 second, Scale 0-99, Dimensions: 13 cm x Ø 2.4 cm, Weight: 85 g, Cable length: 1.3 m



  pH: Measuring range: pH 0 to pH 11, Resolution: 0.1 pH, Length: 26.5 cm, Weight: 116 g, Cable length: 1.3 m



  TEWL-Index: "Open-chamber-measuring-principle", Measuring time 15 seconds, Units: index values: 0-20, Length: approx. 12 cm, Weight: approx. 40 g, Cable length: 1.3 m



  Temperature: Measuring principle: infrared, Resolution: 0.1 °C, Dimensions: 13.5 x Ø 2.4 cm, Weight: approx. 68 g, Cable length: 1.3 m



  Colour measurement: Measuring principle: reflection, measuring area: 8 mm Ø, time: 1 second, Scale L*a*b, Dimensions: 13 x Ø 2.4 cm, Weight: ca. 68 g, Cable length: 1.3 m



  Visioscope® PC 35 USB skin camera



  Sebufix® F 16: Milky foil to determine the sebum content qualitatively, Dimensions: 1.7 x 1.7 cm, Thickness: 0.2 mm



  Corneofix® F 20: Transparent foil to assess desquamation, Dimensions: 2.00 x 1.95 cm, Thickness: 0.1 mm



  Foils are completely harmless for the skin



  Visiopor® PP 34 USB camera to monitor porphyrin fluorescence (for direct connection to your computer)



  Computer: Windows® 10/11, USB 2.0/3.0, computer performance must meet system requirements (please ask for details).





  Technical changes may be made without prior notice.
